CPU
|
H5 Quad-core 64-bit Cortex-A53
|
|
GPU
|
Hexa-core Mali450 OpenGL ES 2.0/1.1/1.0
OpenVG 1.1
EGL 40 GFlops
Pixel fill rate greater than 2.7GPixel/s
|
|
Memory (SDRAM)
|
512MB DDR3 (shared with GPU)
|
|
Onboard Storage
|
TF card (Max. 32GB) / Spi flash(2MB)
|
|
Wifi Antenne
|
Yes
|
|
Onboard WIFI
|
Realtek RTL8189FTV, IEEE 802.11 b/g/n
|
|
Onboard Network
|
1000M/100M/10M Ethernet RJ45
|
|
Audio Input
|
No
|
|
Video Outputs
|
Supports external board via 13pins
|
|
Power Source
|
USB OTG can supply power
|
|
GPIO(1x3) pin
|
UART, ground.
|
|
USB 2.0 Ports
|
One USB 2.0 HOST, One USB 2.0 OTG
|
|
Buttons
|
Power Button(SW602)
|
|
Low-level peripherals
|
26 Pins Header,
13 Pins Header, with 2x USB, IR pin, AUDIO(MIC, AV)
|
|
LED
|
Power led & Status led
|
|
Supported OS
|
Android5.1, Lubuntu, Debian, Armbian Image
|
